Hersteller: Fluke
435 Series II 3-Phase Power Quality & Energy Analyzer w. Current Probes
Fluke 435 Series II 3-Phase Power Quality & Energy Analyzer. – Voltage Inputs: 4 (3 Phase + Neutral) DC-coupled, Maximum Input Voltage 1000 Vrms, Nominal Voltage Range Selectable 1 V to 1000 V, Max. Peak Measurement Voltage 6 kV (Transient Mode only). – Current inputs: 4 (3 Phase + Neutral) DC- or AC-coupled, Range with (4x) included Current Clamps i430flex-TF 0.5 Arms to 600 Arms (Sensitivity 10x) or 5 Arms to 6000 Arms (Sensitivity 1x), Input Impedance 1 MOhm, Bandwidth > 10 kHz, Scaling 1:1, 10:1, 100:1, 1,000:1 10,000:1 and variable.
The new 430 Series II Power Quality and EnergyAnalyzers offer the best in power quality analysisand introduce, for the first time ever, the ability to monetarily quantify energy losses.
The new Fluke 434, 435 and 437 Series II models help locate, predict, prevent, and troubleshoot power quality problems in three-phase and single-phase power distribution systems.
Additionally, the Fluke-patented energy loss algorithm, Unified Power Measurement, measures and quantifies energy losses due to harmonics and unbalance issues, allowing the user to pinpoint the origin of energy waste within a system.
