Fiber connector and ferrule cleaning tool, MTP and MPO, 12F (+600 cleans)

Fiber optic cleaning tool which cleans the male or female side of a connector, for +600 cleanings. It removes contaminants by an easy push operation without damaging the delicate optical fiber cores. The cleaner uses the mechanical push action to advance an optical grade dry cleaning tape while the cleaning tip is rotated to ensure the fiber end-faces are effectively, but gently cleaned. It has an automatic advance feature which ensures each clean is performed with fresh cleaning tape.
Suitable to clean the ferrule inside an MPO and MTP adapter/port (female/receptacle). Secondly it can also be used for cleaning the ferrule end faces of a fiber optic patch cablewith MPO or MTP connectors (male). Includes an instruction manual.

* One push cleaning action
* Auto advance/refresh, no replacement or reloading needed
* Transparent housing, easy to check remaining cleaning cloth
* More then 600 cleans with one pen
* Ergonomic, lightweight pen design
* MPO and MTP adapters/ports (female)
* MPO and MTP plugs of patch cables (male)
* Flat (MM) and 8 degree angled (SM), compatible with or without guide pins.
* Size: Main Body:197L×15W×50H and with cap attached:208L×15W×50H

Many issues in optical communications equipment are caused by contamination of the optical connector end face. A clean connector is critical to the reliability of any optical network architecture. The result of unclean connectors when mating is cross contamination of both connectors and potential damage like scratches to the ferrule end face. Good cleaning techniques, proper training and the use of cleaning tools will help prevent signal degradation, residue cross contamination, and will reduce lasting effects of contamination. Prevention first, but still, the best practice is to always inspect both connectors, before mating. Contact RentalTec sales for information about inspection solutions or more advanced test equipment.
