M8190A 12 GSa/s Arbitrary Waveform Generator

Keysight’s M8190A — A Keysight AWG is the source of greater fidelity, delivering high resolution and wide bandwidth — simultaneously

Precision AWG with two DAC settings
14-bit resolution up to 8 GSa/s
12-bit resolution up to 12 GSa/s
High-speed arbitrary waveform generators
Variable sample rate from 125 MSa/s to 8 / 12 GSa/s
Spurious-free-dynamic range (SFDR) up to 90 dBc typical
Up to 2 GSa arbitrary waveform memory per channel with advanced sequencing
Analog bandwidth up to 5GHz
Unique Performance – Unique Value
Up to 90 dBc SFDR – Tones clearly stand out of noise (Even with thousands of tones)
2 GSa memory per channel – Realistic signal scenarios with long playtime
5 GHz analog bandwidth – Mimic analog imperfections with custom ISI
Key applications
Radar, Satellite, Electronic Warfare, Multilevel Signals
ADC testing (Analog Digital Converter testing), Jitter Margin Testing
Digital Video, Noise Power Ratio Measurement, Wireless HD, HDMI, MHL
IEEE 802.11ad, CaTV, OFDM, Software Defined Radio
