MSO72304DX 4+16-CH, DIGITAL, 23GHz Mixed Signal Oscilloscope

Engineers rely on an oscilloscope throughout their design cycle, from prototype turn-on to production testing. This is where the Tektronix MSO72304DX comes in. Part of the MSO/DPO70000 Series of oscilloscopes from Tektronix, the MSO72304DX’s unique capabilities, combined with exceptional signal acquisition performance and analysis, accelerate your measurement tasks.• Up to 33 GHz analog bandwidth and rise time as fast as 9 ps. Enables measurement on the latest high-speed serial standards
• True 33 GHz Real-time Analog Bandwidth on 2 Channels with 33 GHz models
• Industry-leading sample rate and timing resolution
• 100 GS/s on 2 Channels (33, 25, 23, 20, 16, and 12.5 GHz models)
• Four-channel Simultaneous Performance
• Up to 23 GHz Bandwidth
• Up to 50 GS/s Real-time Sample Rate
• Up to 500 Megasample Record Length with MultiView Zoom- for quick navigation
• Fastest Waveform Capture Rate with >300,000 wfms/s maximum per channel
• 16 Logic Channels with 80 ps Timing Resolution for Debug of digital and analog signals (MSO70000 Series only)
