MSOX3054A 4+16 channel MSO 500MHz, Mixed Signal Oscilloscope

The Keysight MSOX3054A is a mixed signal oscilloscope, which belongs to the Keysight MSOX3000 series. The MSOX3000-Series is the industry’s first 4-in-1 product with a full-featured scope, logic analyzer, protocol analyzer, and a function generator all integrated into one design with a large, 8.5-inch display. The 4-channel InfiniiVision Oscilloscope model has, 4 analog 16 digital-channels, up to 500 MHz bandwidth, with 1,000,000 waveforms/ sec. 2 GSa/s per channel, 4 GSa/s half-channel interleaved mode.
Apart from having various functions expected in mid-range oscilloscopes, the company’s 3000 X series can also be used as a signal source. It is designed with a built-in function generator that produces square, sine, ramp and pulse signals as frequencies up to 10 MHz square and pulse, 100-kHz ramp and 20 MHz (sine wave). The function generator is offered as an upgrade or as an option.
Important features of the Keysight MSOX3054A oscilloscope include:
2 – 4 Analog channels
16 Digital timing channels with the MSO
Sample rate of 2 G Sample/s per channel, 4 G Sample/s half channel interleave mode
Memory depth of 2 M points standard, 4 M points optional
Waveform update rate up to 1000000 waveforms per second
Built in WaveGen up to 20MHz
Bandwidth:
500 MHz
Display Size:
8.5 inch
ADC Resolution:
8 bits
