FSV7 7 GHz Spectrum Analyzer, Type N (f)

The Rohde & Schwarz FSV7 is signal and spectrum analyzer used to develop, produce, install and service RF systems. A touchscreen for easy operation, compact dimensions, low weight and direct support of power sensors makes the Rohde & Schwarz FSV7 the best choice for installation and service work.
In development applications, the R&S FSV7 showcases its excellence with RF properties, large bandwidth of 160 MHz signal analysis, and a wide range of analysis packages for analog modulation methods as well as wireless and wideband communications standards.
Rohde & Schwarz FSV7 – Features and Specifications:
Frequency range up to 4, 7, 13.6 GHz
40 MHz analysis bandwidth
0.4 dB level measurement uncertainty up to 7 GHz
Measurement applications for GSM/EDGE (including EDGE Evo Evolution), WCDMA/HSPA , LTE, WiMAX, WLAN, CDMA2000, 1xEV-DO, vector signal analysis
Easy on-site upgrading with options
-110 dBc (1 Hz) phase noise at 10 kHz frequency offset
15 dBm third order intercept (TOI)
Displayed average noise level (DANL) in 1 Hz bandwidth:
-155 dBm at 1 GHz
Removable hard drive for applications
The Rohde & Schwarz FSV7 comes with 365 customer support and is available for rent at Rentaltec
