FSWP8 8GHz Phase Noise Analyser and VCO Tester, Type N (f)

The Rohde & Schwarz FSWP8 is a Phase Noise Analyzer and VCO Tester that offers a frequency range of up to 8 GHz. The FSWP8 comes with the brand’s cross-correlation technology and low-noise internal sources in order to offer high sensitivity for phase noise measurements.
Key facts of the R&S FSWP8:
Frequency range from 1 MHz to 8 GHz
Simultaneous measurement of amplitude noise and phase noise
Measurement of phase noise on pulsed sources at the push of a button
Internal source for measuring additive phase noise, including on pulsed signals
Signal and spectrum analyzer and phase noise analyzer in a single box
High-end signal and spectrum analyzer, 10 Hz to 26.5 GHz
Wide dynamic range thanks to low displayed average noise level (DANL) of -156 dBm (1 Hz) (without noise cancellation) and high TOI of typ. 25 dBm
320  MHz signal analysis bandwidth (optional)
Total measurement uncertainty:
< 0.2 dB up to 3.6 GHz,< 0.3 dB up to 8 GHz Touchscreen operation Large 12.1” display for simultaneous viewing of multiple measurement windows Various measurement applications can be run and displayed in parallel High measurement speed Low-noise internal DC sources for VCO characterization Automatic VCO characterization Analysis of up to 8 GHz wide frequency hops (transients)
