MA5150 Memory analyzer with LPDDR5 performance, margins and capture

Accurately monitor and measure bus traffic, optimize memory performance, validate memory and debug with the Nexus Technology MA5150 memory analyzer with LPDDR5 performance.
The MA5150 is best suited for applications involving LPDDR5, LPDDR4, LPDDR4x and LPDDR3. Featuring real-time memory performance metrics, real-time memory compliance margins and validation, and real-time smart single frequency, this memory analyzer can efficiently analyze thousands of real-time memory parameters and perform quick summary runs as well as in-depth extended data logging or margin testing runs.
The Nexus MA5150 can be used in applications such as advanced listing, waveform, tables and charting.
Nexus Technology MA5150 – Features and Specifications:
LPDDR5-6400
LPDDR4-4267
LPDDR4x-4267
ClockSafe™:
Continuous analysis across clock stops and clock frequency changes
Number of input channels:
20
Acquisition depth:
1G-sample
Programmable probe termination
11ps x 10mV x 20-channel analog characterization (iCiS™)
Analog eye characterization on 20-channels simultaneously at 11ps x 10mV
Real-time smart single frequency or 16 frequency analysis
Real-time memory performance metrics
Real-time memory compliance margins and validation
Trigger in and trigger out
Integrated Windows 10 Controller
The Nexus Technology MA5150 memory analyzer with LPDDR5 performance is available for rent at Rentaltec
