N5227B-200 2-port, 10 MHz – 67 GHz PNA Network Analyzer, 1.85 mm (m)

Use the Keysight N5227B-200 PNA network analyzer to measure S-paramerters confidently and with the highest stability. The N5227B-200 is the best-performing microwave network analyzer in the industry and is the perfect solution for your toughest measurement challenges and requirements.
Characterize active components and get quick, accurate insights into component behavior with the Keysight N5227B network analyzer’s multi-touch display and intuitive user interface.
Keysight N5227B-200 Features and Specifications:
Two-port base model with standard test set
Maximum frequency:
67GHz
Nominal (preset) power:
0 dBm
Minimum settable power:
-30 dBm (typical)
Damage input level:
27 dBm, 40 V
Input frequency:
10MHz 10 ppm
Input level:
-15 dBm to 20 dBm
Input impedance:
200 ohmes, nominal
Output frequency:
10MHz 1 ppm
Output level:
10 dBm 4 dB into 50
ohmes
Output impedance:
50 ohmes, nominal
The Keysight N5227B-200 two-port, 67GHz PNA network analyzer is available for rent at Rentaltec
