SDA-808ZI-A 4 channel 8 GHz Oscilloscope

The Teledyne LeCroy SDA-808Zi-A 8 GHz Digital Oscilloscope built for exceptional performance, features up to 30 GHz bandwidth, 80 GS/s sample rate, extremely stable timebase and a 14.1 Gb/s serial to capture high-speed signals. The SDA-808Zi-A is a four-channel oscilloscope that comes with bandwidth upgradability, making it affordable and stays up-to-date with emerging serial data standards and high-speed technologies.
The Teledyne LeCroy SDA-808Zi-A features a high-resolution, large 15.2 WXGA color touch screen that allows you to combine multiple analysis types into a single, correlated display:
analog signals, protocol decodes, eye diagrams, measurement parameters, and other relevant information are presented side-by-side, in real-time. The SDA-808Zi-A also offers the lowest jitter noise floor while remaining stable over long acquisitions.
Teledyne LeCroy SDA-808Zi-A – Features and Specifications:
Bandwidth up to 30 GHz
Cutting-edge oscilloscope user interface
True hardware 14.1 Gb/s serial trigger
15.3 flat panel Color LCD with high resolution touch screen
Maximum sampling rate of 40 GS/s (80 GS/s with optional WM8Zi-2X80GS external interleaving device)
DC and timing accuracy Auto calibration -maintained for
one year minimum
Max. Power Consumption of 975 W / 975 VA
Serial data analysis, debug, validation and compliance tools
Integrated 50 O and 1 MO inputs for true connection and probing flexibility
Multi-lane serial data eye, jitter and crosstalk analysis
Real-time de-embedding, emulation, and equalization
The Teledyne LeCroy SDA-808Zi-A comes with 365 customer support and is available for rent at Rentaltec
