U8975 4 Channel Analog Unit

The Hioki U8975 is a 4-channel Analog Unit for the Hioki Memory HiCorder MR6000. The Hioki U8975 can measure up to 32 channels at 5 MS/s with 16-bit resolution (when using 8 modules).
Hioki U8975 – Features and Specifications:
Measurement range:
4, 10, 20, 40, 100, 200 V f.s., 6 ranges
Highest sampling rate:
5 MS/s (4 channel simultaneous sampling)
Insulated 4-channel input (ground-to-ground AC, DC 300 V)
Input terminals:
Isolated BNC terminal (Input impedance:
1 MO, Input capacitance:
30 pF)
High resolution measurement with 16 bit A/D conversion
For Memory HiCorder MR6000 only
