Fabrikant: Keysight
16804A 136-Channel Portable Logic Analyzer
The Keysight, 16804A is a portable logic analyzer that allows its users to debug, validate and optimize digital systems.Logic Analyzer Configuration
15-inch (38.1 cm) color display with touch screen available
136-channel portable logic analyzer with up to 32 M acquisition memory depth
Comprehensive single-ended signal support, threshold is adjustable in -5 V to 5 V (10 mV increments) Timing Analysis (Asynchronous Sampling)
4 GHz (250 ps) timing zoom with 64 K memory
1.0 GHz / 500 MHz (half / full-channel) conventional timing with deep memory
500 MHz transitional timing State Analysis (Synchronous Sampling)
State clock rates up to 450 MHz
Data rates:
up to 500 Mb/s
Automated threshold/sample position setup for accurate measurements on high-speed buses
Simultaneous eye diagrams on all channels identify problem signals quickly Configuration Considerations
Selectable memory depths:
1 M, 4 M, 16 M, 32 M
Compatible with 40-pin logic analyzer probes
