Fabrikant: Narda
745-69 18 GHz, 69 dB, Variable Attenuator
Perform efficient signal conditioning and effective level control with the Narda 745-69 variable attenuator above 4GHz to 18GHz. The Narda 745-69 can be used to reduce signal levels, match the impedances of sources and loads, and measure the gain or loss of two-port devices.
Narda 745-69 Features and Specifications:
Broadband DC-18GHz
Precision 1dB or 10dB steps, to 69dB
Connector:
Type N (F)
Attenuation:
0-69 in 1dB steps
Able to reset per drum:
< 0.05dB
Power average:
2W
Power peak:
0.2 kW at duty cycle of 0.0001
VSWR:
DC-12.4GHz:
1.50; 12.4-18GHz:
1.65
Impedance:
50 ohms
Temperature stability:
0.0001 dB/dB/ degrees C
