86108B 2 Ch Oscilloscope Receiver with Internal Clock Recovery

As high-speed electrical communication systems and components increase in data rates to 25 Gb/s and beyond, design and validation engineers are faced with the difficult task of accurately characterizing the true performance of their designs. The Keysight Technologies, Inc. 86108B Precision Waveform Analyzer is a plug-in module used with the 86100C/D Infiniium DCA family of oscilloscopes that provides an ideal solution to this measurement challenge. With industry-best residual jitter well below 70 femtoseconds (  Bandwidths to 50 GHz
  Ultra-low timebase jitter < 50 fs rms (typical)• Continuous data rate coverage from 50 Mb/s to 32 Gb/s • Adjustable clock recovery loop bandwidth/peaking    Integrated clock recovery (CR) to 32 Gb/s
