86116C 40 to 65 GHz Optical and 80 GHz Electrical Plug-in Modules

The Keysight 86116C is a 40 to 65 GHz Optical and 80 GHz Electrical Plug-in Module that represents some of the fastest solutions available for measuring high-speed communication signals. Typically with 70 GHz optical and 93 GHz electrical bandwidth, the 86116C when paired with the 86107A precision timebase module becomes the ideal solution for high-speed waveform analysis.
The unfiltered bandwidth settings of the Keysight 86116C provide the best pulse fidelity mode for measurement and display of very high-speed waveforms and provides a fast full-width, half-max (FWHM) of less than 7.4 ps (86116C-040).
The 86116C has user selectable bandwidth settings that can reduce instrumentation noise when observing small signals. The electrical channel of the 86116C yields a 3.9 ps system risetime, and has a well-controlled frequency response to minimize waveform distortion.
Keysight 86116C – Features and Specifications:
40 to 65 GHz optical and 80 GHz electrical plug-in modules
70 GHz characteristic optical bandwidth displays up to 107 Gb/s NRZ
93 GHz characteristic electrical bandwidth
Wavelength range 1300 nm to 1620 nm
Connector for fiber input is user-changeable Calibrated Wavelength
(DC Responsivity) 1310 nm and 1550 nm
High-speed telecom signals can be accurately characterized
Tests high-speed LAN/SAN signals
