8714ET 2-port, 300 kHz – 3 GHz RF Network Analyzer, Type N (f)

Network Analyzer, 3 GHz, Includes T/R Test Set. Form Factor:
Benchtop. Type:
Vector. Integral Signal Source:
Yes. Integral Test Set:
T-R Parameter. Source Minimum Frequency:
300 kHz. Source Maximum Frequency:
3 GHz. Source Frequency Resolution:
1 Hz. Source Frequency Accuracy:
0.0005 %. Minimum Output Power:
0.001 Watts. Maximum Output Power:
19.9526 mW. Output Accuracy:
1 dB. Output Impedance:
50 Ohm. No. of Receiver Channels:
2 ch. Receiver Minimum Frequency:
300 kHz. Receiver Maximum Frequency:
3 GHz. Minimum Dynamic Range:
100 dB. Maximum Dynamic Range:
100 dB. Maximum Input Decibel:
20 dBm. Input Connector Type:
Type-N(f).
