E4405B 13.2 GHz Portable Spectrum Analyzer, Type N (f)

The Keysight E4405B ESA-E Series is a mid-performance spectrum analyzer solution for the future. The series sets the performance standards in measurement speed, dynamic range, accuracy, and resolving power for similarly priced products. Its flexible platform design enables R&D, manufacturing, and field service engineers to customize the product to meet specific testing needs and to upgrade the product with new features when required.
The Keysight E4405B’s selection of one button measurement solutions combined with its easily navigable user interface and performance in speed allows engineers to spend less time testing and more time designing, building, and troubleshooting components and products.
Features of the Keysight E4405B:
Noise Figure Measurement Personality
Remotely view and control the ESA over the Internet
8590-series programming code compatibility
8566/68B programming code compatibility
Modulation analysis measurement personality
Bluetooth, GSM/GPRS and cdmaOne standards compliant measurement personalities
Fault location, phase noise, CATV service measurement personalities
Rugged and portable for lab grade performance in the field
One-millisecond RF sweep time, 45 measurements per second
RMS, peak, neg peak, quasi-peak detectors
0.4 dB overall amplitude accuracy
Optional 1 Hz digital-resolution bandwidth filter and preamplifier
-167 dBm sensitivity, with internal preamp, 16 dBm TOI
Variable sweep (trace points) from 2 to 8192
Segmented sweep for up to 32 discontinuous spans in one sweepRent or buy the Keysight E4405B Spectrum Analyzer from
