Fabrikant: Tektronix
MDO3034 4 channel 350MHz Mixed Domain Oscilloscope
Today’s integrated designs need an oscilloscope that is just as integrated – such as the MDO3034 Mixed Domain Oscilloscope (MDO) Series. It is the ultimate 6-in-1
integrated oscilloscope that includes an integrated spectrum analyzer, arbitrary function generator, logic analyzer, protocol analyzer, and digital voltmeter/counter. The MDO3034 is completely customizable and fully upgradeable. Add the instruments and performance you need now – or later.
Key performance specifications:
Oscilloscope 2 and 4 analog channel models
1GHz, 500MHz, 350MHz, 200MHz, 100MHz bandwidth models
Bandwidth is upgradable (up to 1GHz)
Up to 5 GS/s sample rate
10M record length on all channels
>280,000 wfm/s maximum waveform capture rate
Standard passive voltage probes with 3.9
pF capacitive loading and 1GHz, 500MHz, or 250MHz analog bandwidth
