N5183A-532 100 kHz – 31.8 GHz MXG Analog Signal Generator, 2.4 mm (m)

There are numerous applications of the Keysight N5183A-532 31.8 GHz MXG Analog Signal Generator. N5183A-532’s applications include:
Parametric testing of microwave components and receivers
Performing local oscillator (LO) upconversion for microwave backhaul links
CW blocking for receiver testing
Testing throughput with 600–s frequency switching
Characterizing microwave filters and amplifiers.
Here is a detailed look at the specifications offered by the Keysight, N5183A-532.
N5183A-532 – Specifications
Frequency:
100 kHz to 31.8 GHz

Output Power @1 GHz:
-130 dBm to 18 dBm

Phase Noise @1 GHz (20 kHz offset):
-116 dBc/Hz

Frequency Switching:
< 600 -s Harmonics @1 GHz: <-30 dBc IQ Modulation BW Internal/External: n/a Sweep ModeList StepBaseband Generator Mode: n/a Software-General PurposeAM, FM, PM Pulse Pulse Train GeneratorSoftware-Cellular/Wireless Connectivity: n/a Software-Audio/Video Broadcasting: n/a Software-Detection/Positioning/Tracking/Navigation: n/a Waveform Playback Memory: n/a Frequency Modulation-Maximum Deviation @1 GHz: 10 MHz Frequency Modulation-Rate @100 kHz Deviation: DC to 7 MHz Phase Modulation-Maximum Deviation in Normal Mode: 1.25 rad to 160 rad Phase Modulation-Maximum Deviation in High-BW Mode: 0.125 rad to 16 rad Amplitude Modulation-Maximum Depth: 90% Amplitude Modulation-Rate: 0 to 10 kHz Applications Available: Yes Non-Harmonics @1 GHz = 70 dBc
