N5183A-540 100 kHz – 40 GHz MXG Analog Signal Generator, 2.4 mm (m)

The Keysight N5183A MXG is a 40 GHz economy class, continuous wave (CW) signal generator specifically designed to maximize uptime and reduce cost of ownership. It is less than or equal to 900-microsecond switching speed enables a dramatic increase in throughput. The N5183A 540 comes in a simple design which delivers easy self-maintenance that reduces downtime to one working day, making it possible for users to maintain or repair the instrument in-house. Not only does this capability maximize uptime, it also drives a lower cost of ownership.• Signal Characteristics 100 kHz to 40 GHz
• 18 dBm at 20 GHz output power
• = <900 us frequency switching speeds • -98 dBc/Hz typical phase noise at 20 kHz offset • Modulation and Sweep AM, FM, FM • pulse modulation < 10 ns pulse rise/fall time and 20 ns pulse widths • Digital and step sweep • Automation and Communication Interface 100BaseT LAN, USB 2.0 and GPIB • Baseband Generator Mode: Waveform Playback and Real-Time • LXI class-C compliant
