SDA-830ZI-B 4 Ch 30 GHz Serial Data Analyzer

The Teledyne LeCroy WaveMaster SDA-830Zi-B is a 4-channel, 30 GHz serial data analyzer that combines exceptional performance, signal fidelity and feature set and is designed for today’s high-speed measurements with the ease of use of a standard benchtop oscilloscope. Built to simplify the most complex testing, the SDA-830Zi-B features the highest-speed serial data triggers, the only complete multi-lane serial data analysis and eye diagram solution, and the most comprehensive set of compliance packages.
With an extremely stable timebase, up to 30 GHz bandwidth, 80 GS/s sample rate, and a 14.1 Gb/s serial trigger, the Teledyne LeCroy SDA-830Zi-B is a revolutionary instrument, designed to solve complex problems. The SDA-830Zi-B’s MAUI user interface, along with the 15.3 high-resolution touchscreen and flat menu structure, keep the most common tools handy, while making advanced analysis easy to set up and use.
Teledyne LeCroy SDA-830Zi-B WaveMaster Oscilloscope – Features and Specifications:
Up to 30 GHz bandwidth and 80 GS/s sample rate
4 input channels
Cutting-edge oscilloscope user interface
14.1 Gb/s serial trigger – the industry’s only true hardware
Low Jitter Measurement Floor and exceptional timebase stability
Broad set of serial data analysis, debug, validation and compliance tools
True connection and probing flexibility through Integrated 50 ohms and 1 M ohms inputs
Unrivaled analysis capability through Integrated standard and custom measurements and math functions
Multi-lane serial data eye, jitter and crosstalk analysis
Real-time de-embedding, emulation, and equalization
