ZVA24 24GHz Vector Network Analyzer, 3.5 mm (m)

The Rohde & Schwarz ZVA24 performs accurate filter measurements requiring maximum dynamic range, linear and nonlinear measurements on amplifiers and mixers, as well as receivers and transceivers.
With its fast synthesizers, wide IF bandwidths and high dynamic range, the Rohde & Schwarz ZVA24 offers exceptionally short measurement times in both labs and production. It also supports simultaneous measurement of noise figure and S-parameters.          Frequency range:
10 MHz to 24 GHz
          Pulse profile measurements with 12.5 ns resolution
          True differential measurements for reliable characterization of active devices with balanced ports
          Wide dynamic range (typical) > 140 dB
          High output power (typical) > 15 dBm
          Wide IF bandwidth:
1/5/30 MHz
          High measurement speed < 3.5 us per test point           Versatile calibration techniques: TOSM, TRL/LRL, TOM, TRM, TNA, UOSM           Automatic calibration units
