DSA72004 4Ch 20GHz Digital Serial Analyzer

The Tektronix DSA72004 is a high-end data analyzer that enables serial data analysis for technicians investigating all kinds of digital hardware. Belonging to the DSA 7200 series, a new generation of digital phosphor oscilloscopes, it provides the best solution for signal integrity issues.
With accurate signal acquisition and comprehensive analysis and compliance tools, the DSA72004 delivers flexible, high-performance triggering, with FastAcq mode finding infrequent glitches and reducing the time needed for troubleshooting.
Tektronix DSA72004 – Features & Specifications:
20 GHz and 18 GHz Bandwidth
Hardware Analog Bandwidth (-3dB) 16 GHz (typical)
Up to 50 GS/s Real-time Sample Rate
Up to 200 Megasamples Record Length with MultiView Zoom Feature for Quick Navigation
Fastest Waveform Capture Rate with greater than 300,000 wfms/s Maximum per Channel
Digital Serial Analyzer Model with Dedicated Configuration for High-Speed Serial Design and Compliance Testing
Supports Advanced Signal Integrity through Improved Bandwidth that Extends Support to Multiple Bandwidth Steps
Features Pinpoint Triggering with more than 1400 combinations to handle various triggering situations
Unique Serial Pattern Triggering up to 3.125 Gb/s and 8b/10b Standard Protocol Triggering for Isolation of Pattern-dependent Effects
Resolution 20 ps (50 GS/s)
Serial Data Analysis and Compliance for PCI Express, Serial ATA, FB-DIMM, SAS, Fiber Channel, IEEE1394b, RapidIO, XAUI, HDMI, DVI, Ethernet, USB 2.0
Jitter and Timing Measurement and Analysis Package
12.1 in Largest XGA Touch Screen Display in the Industry
MyScope Custom Windows Enhance Productivity
Right-Mouse-Click Menus for Exceptional Efficiency
OpenChoice Software with Microsoft Windows XP OS
Tektronix DSA72004 is available for rent and at
