MDO4054B-3 (4) 1GHz ch. (16) digital ch. (1) 6 GHz RF ch. MDO

The Tektronix MDO4104-6 is a high performance mixed domain oscilloscope from Tektronix. The MDO4104-6 packs a variety of features that make it one of the best products in the market today.
Features and specifications of the Tektronix MDO4104-6:

4 Analog Channels
500MHz or 1GHz bandwidth models
16 Digital ChannelsMagniVu high-speed acquisition provides 60.6 ps fine timing resolution
1 RF Channel
50kHz – 3GHz or 50kHz – 6GHz
Standard Passive Voltage Probes 3.9
pF:
capacitive loading and 500
MHz or 1GHz analog bandwidth
Mixed Domain AnalysisTime-correlated analog, digital, and RF Signal Acquisitions in a single instrument
Wave Inspector Controls provide easy navigation of time-correlated data from both the time and frequency domains
Amplitude, frequency, and phase vs. time waveforms derived from RF Input
Selectable spectrum time to discover and analyze how RF Spectrum changes over time; even on a stopped acquisition
