MDO4104C 4 Analog Channels 1GHz Bandwidth Models, 16 Digital

The Tektronix MDO4104C mixed domain oscilloscope is a 6-in-1 integrated oscilloscope that includes a spectrum analyzer, arbitrary/ function generator, logic analyzer, protocol analyzer and Digital Voltmeter/frequency counter. When configured with an integrated spectrum analyzer, Tektronix MDO4104C has the distinction of being the only instrument that provides simultaneous and synchronized acquisition of analog, digital and spectrum; ideal for incorporating wireless communications (IoT) and EMI troubleshooting.
With the capabilities you need to solve the toughest embedded design challenges quickly and efficiently, the MDO4000C is completely customizable and upgradeable allowing you to add the instruments you require now – or as the need arises.
Tektronix MDO4104C – Features and Specifications:
Synchronized analysis of analog, digital, and RF signals for easy system-level troubleshooting
4 analog channels
16 digital channels MagniVu
1 GHz bandwidth
350 ps rise time
Digital phosphor technology with High-Speed Waveform Capture
5 GS/s sample rate
20 M record length on all channels
Over 125 trigger combinations providing a complete set of triggers
With more than 340,000 waveform/s capture rate, identify glitches and other infrequent transient signals quickly
Optional built-in 3 GHz or 6 GHz spectrum analyzer
Optional arbitrary/function generator
Optional 16-channel logic analyzer w/ 20 M record length on all channels
Optional protocol analyzer
The Tektronix MDO4104C comes with 365-day customer support and is available for rent at Rentaltec
