N5247A-419 4-Port, 10 MHz – 67 GHz PNA-X Network Analyzer, 1.85 mm (m)

The N5247A PNA-X network analyzer is the world’s most integrated and flexible single-connection microwave test engine for measuring active devices such as amplifiers, mixers, and frequency converters.

Maximum Frequency 67 GHz
Dynamic Range 129 dB
Output Power 13 dBm
Trace Noise 0.002 dBrms
Number of Built-In Ports 2 or 4 ports
Harmonics -60 dBc
Noise Floor -118 dBm
S-Parameters
Noise Figure
Gain Compression
X-Parameters
Balance Measurements
Pulsed RF
IMD
Best Speed at 201 Point, 1 Sweep 9.7 ms
