Hersteller: Teledyne LeCroy
SDA-816ZI 4 Ch 16 GHz Serial Data Analyzer
The Teledyne LeCroy SDA-816Zi is a four channel realtime oscilloscope which offers up a bandwidth of 16 GHz. The SDA-816Zi forms part of the SDA 8 Zi series of devices from Teledyne LeCroy. The SDA 8 Zi Series SDA 8 Zi Serial Data Analyzers are based on the WaveMaster 8 Zi Series oscilloscope and are equipped with double the standard memory to capture more unit intervals in the eye diagram. The SDA 816Zi includes an enhanced high-speed serial pattern trigger that operates on up to 80 bit patterns and at speeds up to 3.125 Gb/s. Whether debugging eye pattern or other compliance test failures, the SDA 816Zi rapidly isolates the source of the problem in your design.
Here are some of the key features of the SDA-816Zi:
Display Eye Pattern, TIE, Bathtub Curve and Jitter Histogram on the screen at the same time
Create Eye Patterns utilizing the full memory for maximum statistical significance
100 times faster Eye Diagram creation
Gain insight with IsoBER and Mask Violation Locator tools
Request a quote today to
