UXR0704A Infiniium UXR Real-Time Oscilloscope, 70 GHz, 256 GSa/s, 4Ch

Develop the next-generation of electronic research and design with the Keysight UXR0704A Infiniium UXR real-time oscilloscope.
The Keysight UXR0704A is the most powerful oscilloscope in the world with the lowest noise and jitter floors, the highest signal fidelity, 10-bit high-definition ADC, 20 femtoseconds (typical) of intrinsic jitter for exceptional jitter characterization, deep memory, and hardware-accelerated processing.
The UXR0704A offers bandwidth upgradability along with high signal integrity to keep up with evolving technological needs. It also includes high-speed SDA and clock recovery, user-defined functions, and an optional calibration module.
Keysight UXR0704A Features and Specifications:
Number of channels:
Four
Maximum bandwidth:
70GHz
Maximum sampling rate:
256GSa/s
Input connector type:
1.85mm male with AutoProbe III jack
Memory depth per channel:
200Mpts (standard) and 2Gpts (maximum)
Minimum input power:

– Four-channel:
200Vac
– Two-channel:
110Vac
Input impedance:
50 ohmes, plus/-3 percent
Displayed input sensitivity:
1mV/div to 500mV/div
Hardware sensitivity:
60mV full scale to 4.0V full scale
Vertical resolution:
10 bits, > 14 bits with averaging
ENOB typical:

– At > 400 mVfs:
5.4
– At 40 mVfs:
5.0
Offset accuracy:
plus/- 2 percent of channel offset 1 percent of full scale
The Keysight UXR0704A Infiniium UXR real-time oscilloscope is available for rent at Rentaltec
