CA8336 Power quality & energy analyser w. A193-800 current probes

Designed for test and maintenance teams working in industrial or administrative buildings, the Qualistar+ C.A 8336 can be used to obtain a snapshot of the main features characterising the quality of the electrical network.. This analyser’s functions make it the ideal instrument for preventive or corrective maintenance. It can also be used to perform a complete energy survey of an installation.

Technical specifications:

• TRMS AC+DC voltage up to 1,000 V
• TRMS AC+DC current: 5 mA to 10 kA depending on the sensors
• Frequency
• Power values: W, VA, var, VAD, PF, DPF, cos f, tan f
• Energy values: Wh, varh, VAh, VADh, BTU, toe, Joule,
• Harmonics from 0 to the 50th order, phase
• Transients: up to 210
• Inrush with waveform over a period > 10 minutes
• TrueInrush function
• Recording of a selection of parameters at the maximum sampling rate for several days to several weeks
• Alarms: 10,000 of 40 different types
• Peak detection
• Vectorial representation
• Available in more than 27 languages
• IP53 / IK08
• USB communication
• IEC 61000-4-30 Class B
• Dimensions / weight: 240 x 180 x 55 mm / 1.9 kg

All the Qualistar+ models are delivered with a set of rings/inserts for quick identification and customization of the colour coding for each country. Large choice of current sensors for current measurements from 5 mA to 10 kA.

Optional, the ESSAILEC cable can be used to carry out tests without disturbing or interrupting the power supply circuit on the meters and the protection relays installed in the secondary circuits of current or voltage transformers. Reeling Box: This practical magnetized winder equipped with the MultifFIX system allows you to adjust the length of your cables. It can be opened so that users can install banana-type leads for voltage measurements or MiniFlex® MA193-250 flexible sensors for current measurements. It also provides a simple means of stowing your cables. PA31ER adapter: This enables self-powering of the Qualistar+ via the phase from 100 V to 1,000 V, AC or DC. It is connected directly to the voltage inputs and is:

• IP53
• IEC 61010 CAT III 1,000 V / CAT IV 600 V.
