FSVA3004 Signal & spectrum analyser, 10Hz-4GHz, N(f)

Rohde & Schwarz FSVA3004 Signal & spectrum analyser, frequency range 10 Hz – 4 GHz, type N(f). (1330.5000.05)

• FSV3-B114 – CPU board with enhanced computing power and memory size
• FSV3-K40 – Phase Noise Measurement Application

The right instrument for demanding signal analysis tasks in the lab and on a production line.
Analysis bandwidth of up to 1 GHz, outstanding phase noise of –120 dBc/Hz and a high dynamic range give the R&S FSVA3000 signal and spectrum analyzer everything needed for demanding 5G NR measurement applications.
High measurement speeds and easy usability make it ideal for demanding signal analysis, both in the lab and on the production line.

Ready for 5G and other wireless standards
The R&S FSVA3000 signal and spectrum analyzer is ideal for evaluating wireless communications signals in R&D, system testing, verification and production.
With 400 MHz of analysis bandwidth, it can capture four neighboring 5G NR carriers at once.
The dedicated options for 5G NR signal analysis enable EVM values better than 1% for a 100 MHz wide carrier at 28 GHz.

Key facts

• Frequency range from 2 Hz to 4, 7.5, 13.6, 30, 44, 50/54 GHz
• Analysis bandwidth up to 1 GHz
• SSB phase noise at 10 kHz offset (1 GHz): –127 dBc/Hz
• GUI with multi-touch, SCPI recorder and event based actions
• Options for analog and digital signal analysis, including 5G NR
