FSWP50 50GHz Phase noise analyser VCO tester, 1.85mm (m)

Rohde & Schwarz FSWP50 , 1 MHz to 50 GHz (1322.8003.51)

The R&S FSWP phase noise analyser and VCO tester is very sensitive thanks to extremely low-noise internal sources and cross-correlation. It can measure phase noise and amplitude noise in mere seconds on highly stable sources such as those in radar applications. Additional options such as pulsed signal measurements, residual phase noise (including pulsed) characterization and integrated high-end signal and spectrum analysis make the R&S FSWP a unique test instrument.

• Frequency range from 1 MHz to 50 GHz

• Simultaneous measurement of amplitude noise and phase noise

• Measurement of phase noise on pulsed sources at the push of a button

• Internal source for measuring additive phase noise, including on pulsed signals

• Signal and spectrum analyser and phase noise analyzer in a single box

• High-end signal and spectrum analyser, 10 Hz to 26.5 GHz

• Wide dynamic range thanks to low displayed average noise level (DANL) of -156 dBm (1 Hz) (without noise cancellation) and high TOI of typ. 25 dBm

• 320  MHz signal analysis bandwidth (optional)

• Total measurement uncertainty: < 0.2 dB up to 3.6 GHz,< 0.3 dB up to 8 GHz • Touchscreen operation
