DSA70804B 4 Ch 8 GHz Oscope

The DPO70000B and the DSA70000B Series real-time digital phosphor oscilloscopes (DPOs) are ground-breaking solutions to the challenging signal integrity issues faced by designers characterizing, debugging, and testing sophisticated electronic designs. The specialized DSA70000B Series, which includes the DSA70804B realtime oscilloscope, provides a complete and dedicated solution to address the challenges of high-speed serial designs. The family features exceptional performance in signal acquisition and analysis, operational simplicity, and unmatched debugging tools to accelerate your day-to-day tasks.
A large display and the intuitive user interface provide easy access to the maximum amount of information. High bandwidth up to 20 GHz matched across 2, 3, or 4 channels and enabled by Tektronix proprietary bandwidth enhancement. The user-selectable filter for each channel provides magnitude and phase correction for more accurate representation of extremely fast signals. In addition, only Tektronix allows the user to disable the bandwidth enhancement for applications needing the highest measurement throughput. Bandwidth enhancement eliminates imperfections in frequency response.
