DSOS404A 4 Ch 4 GHz Oscilloscope – Infiniium S Series

The Keysight DSOS404A Real Time Oscilloscope is part of the Keysight Infiniium S-series of high definition oscilloscopes.
The Keysight Infiniium S-Series high-definition oscilloscopes incorporate new technology to deliver superior measurements. A 10-bit ADC, low-noise front end, correction filters, vertical scaling support down to 2 mV/division, and a precise time base produce high-fidelity measurements. In addition, its advanced frame and broad range of capability enable the S-Series oscilloscopes to tackle a wide range of test needs.
Key specifications of the Keysight DSOS404A:
Bandwidth:
4 GHz
Channels:
4
Max Memory Depth:
800 Mpts (2 channels), 400 Mpts (4 channels)
Max Sample Rate:
20 GSa/s (2 channels), 10 GSa/s (4 channels)
Display Size:
15 inch
ADC Bits:
10 bits
Noise Floor:
768 -Vrms at 50 mV/div
Effective Number of Bits (ENOB):
7.2
Typical Rise/Fall Time:
107.5 ps (10-90%), 77.5 ps (20-80%)
