HVD3605 6kV, 100 MHz High Voltage Differential Probe

Achieve exceptionally high Common Mode Rejection Ratio (CMRR) over a broad frequency range with the Teledyne LeCroy HVD3605 high voltage differential probe. The HVD3605 can efficiently meet all measurement challenges in noisy, high common-mode power electronics with its precise high voltage floating measurements with 1% gain accuracy. This differential probe is best suited for automotive, motor drive development, and product design applications.
Teledyne LeCroy HVD3605 – Features and Specifications:
Bandwidth:
100 MHz
Rise time (10-90):
4.3 ns
Differential voltage range (high attenuation):
7000 V (DC peak AC) from 28V/div to 2000 V/div with up to 6000V offset
Differential voltage range (low attenuation):
700 V (DC peak AC) from 300mV/div to 27.5 V/div with up to 600V offset
Common mode voltage range:
plus or minus 7600V (DC peak AC), 6000 Vrms
Sensitivity:
300 mV/div to 27.5 V/div (200X)
28 V/div to 2000 V/div (2000X)
Input impedance:
48 MO || 2.5 pF (between inputs) 24 M ohms
|| 5.0 pF (either input to ground)
Interface:
ProBus
The Teledyne LeCroy HVD3605 6 kV, 100 MHz high voltage differential probe is available for rent at Rentaltec
