Manufacturer: Hioki
IM3570 Hioki LCR Meters and Impedance 4 Hz to 5 MHz
Make frequency sweeps and LCR measurements with one instrument. The Hioki IM3570 works as an impedance analyzer and LCR meter. It has numerous applications in testing electronic components that need a low-ESR measurement of the order of several milliohms.
The IM3570 is ideal for testing the resonance characteristics of piezoelectric elements, C-D and low-ESR measurement of functional polymer capacitors, and DCR and L-Q measurement of inductors like coils and transformers because of its superior low-impedance repeatability.
The Hioki IM3570 is a single device solution for high-speed testing and frequency sweeping.
Hioki IM3570 – Features and Specifications:
Maximum speeds of 1.5ms (1 kHz) and 0.5ms (100 kHz) in LCR mode
Highly accurate measurements with
plus or minus
0.08% basic accuracy of Z parameter
Measurement range of 100 m omega
to 100 M omegaMeasurement frequency of 4 Hz to 5 MHz
5.7 inch color TFT display
