MSO4034B 4+16-CH, DIGITAL, 350 MHz Mixed Signal Oscilloscope

The MSO4034B Mixed Signal Oscilloscope delivers the performance you need to see fast-changing signal details. You can analyse analogue and digital signals with a single instrument. Combine that with automated serial and parallel bus analysis, innovative Wave Inspector® controls, and automated power measurements, and this oscilloscope provides the feature-rich tools you need to simplify and speed debug of your complex design.
20 Megapoint Record Length on All Channels
50,000 wfm/s Maximum Waveform Capture Rate
Passive Voltage Probes with Less than 4 pF Capacitive Loading and 500MHz or 1GHz analogue Bandwidth
Suite of Advanced Triggers
Wave Inspector® Controls provide Easy Navigation and Automated Search of Waveform Data
41 Automated Measurements, Waveform Histograms, and FFT Analysis for Simplified Waveform Analysis
TekVPI® Interface supports Active, Differential, and Current Probes for Automatic Scaling and Units
10.4 in. (264 mm) Bright XGA colour Display
Small Footprint and Lightweight – Only 5.8 in. (147 mm) deep and 11 lb. (5 kg)
USB 2.0 Host Ports on Front and Rear for Data Storage, Printing, and Connecting a USB Keyboard
USB 2.0 Device Port on Rear for PC Connection or Direct Printing to a PictBridge®-compatible Printer
Integrated 10/100/1000BASE-T Ethernet Port and Video Out Port to Export the Oscilloscope Display
Automated Serial Triggering, Decode, and Search Options
Automated Triggering, Decode, and Search on Parallel Buses
Per-channel Threshold Settings
Multichannel Setup and Hold Triggering
MagniVu™ High-speed Acquisition Provides 60.6 ps Fine Timing Resolution on Digital Channels
