Manufacturer: Teledyne LeCroy
WR640ZI 4 Ch 4 GHz Digital Oscilloscope
The Teledyne LeCroy WaveRunner WR640Zi defines superiority in a test instrument. The powerful feature set of the Teledyne LeCroy WR640Zi four channel, 4 GHz Digital Oscilloscope includes the following:
Wide range of application packages
Advanced triggering to isolate events
User interface developed for quick and easy navigation
Wide range of probing options
Lightning-fast performance
Here are the specs of the LeCroy WR640Zi:
Analog Bandwidth @ 50 O (-3 dB): 400 MHz (= 2 mV/div)
Analog Bandwidth @ 1 MO (-3 dB): 400 MHz (typical)
Rise Time (10-90%, 50 O): 875 ps (typical)
Rise Time (20-80%, 50 O): 650 ps (typical)
Input Channels: 4
Bandwidth Limiters: 20 MHz, 200 MHz
Input Impedance: 50 O -2% or 1 MO || 17pF, 10 MO || 9.5 pF with supplied Probe
Input Coupling: 1 MO: AC, DC, GND; 50 O: DC, GND
Maximum Input Voltage: 50 O: 5 Vrms -10 V
peak 1 MO: 400 V max. (DC peak AC < 10 kHz)
Channel-Channel Isolation: > 100:1 up to rated BW
