6692A 60V/110A/6600W System Power Supply

The Keysight 6692A high power (6600 Watt) DC supply offers speed and accuracy for test optimization while ensuring no delays on your testing. The ruggedness and durability of the 6692A is built to meet demanding needs of continuous stress testing in tough environments. Designed with built-in margin, the Keysight 6692A can meet the specifications under all conditions and withstand peak stress.
The low output ripple and noise, analog control of output voltage and current, fan-speed control to minimize acoustic noise, as well as built-in measurements and advanced programmable features make the Keysight 6692A a dependable solution. The 6692A has many safety features available to protect your DUT from damaging conditions like overvoltage, overcurrent, over-temperature, and programmable shut-down.
Keysight 6692A – Features and Specifications:

Output voltage: 0 to 60 V
Output current : 0 to 110 A
Low ripple noise (20 Hz to 20 MHz)
High accuracy current programming and read back
Constant Voltage Peak-to-peak: 25 mV
Parallel connection for more current output
Analog programming and monitoring
Constant current with Load Inductance >5H rms: 30 mA Readback Accuracy (from front panel or over
GPIB with respect to actual output @ 25 /-5C)
Industry standard SCPI programming commands
Remote sense
Electronic calibration
Get the Keysight 6692A for sale or rent from Rentaltec with 24/7 customer support.
Contact us to request a quote today.
