Manufacturer: Keysight
85134F Flexible Cable Set, 2.4 mm to 3.5 mm
The Keysight 85134F is a 62.9 cm (24.75 in) long(1) flexible cable set composed of a 2.4 mm female(2) to PSC-3.5 mm female connector and a 2.4 mm female(2) to 3.5 mm male connector. Cable frequency range is dc to 26.5 GHz with a return loss greater than or equal to 16 dB. Insertion loss is 0.31
* sqrt (f) 0.2, where f is frequency in GHz, for the test port connector and 1.8 dB at maximum frequency for the device connector. Phase stability of semi-rigid/flexible cables is specified with a 90 degree bend using a 4 to 3 inch radius. Stability(1) of the Keysight 85134F is less than 0.12 dB and phase is 0.13
*f 0.5 deg., where f is frequency in GHz. Notes:
(1) Cable length and stability are supplemental characteristics. (2) Special rugged female connector is designed specifically for connecting to the network analyzer test port, but does not mate with a standard male connector.
