E4406A 4 GHz VSA Transmitter Tester, Type N (f)

Use the Keysight E4406A VSA transmitter tester for mobile handset and base station manufacturing and to develop wireless equipment with confidence. This vector signal analyzer from Keysight comes with various power measurements for multiple 2G, 2.5G, 3G, and 3.5G wireless communications formats.
Equipped with one-button standard-based modulation analysis and optional baseband IQ input, it offers speed and accuracy at a great price for volume production. These factors make the E4406A a convenient choice for research and development.
Get measurement speeds up to three times faster than those offered by regular spectrum analyzers. Featuring multiple domain analysis for time, frequency, and code, and one-button standard-based measurement personalities (W-CDMA, HSDPA, cdma2000, 1xEV-DV, cdmaOne, 1xEV-DO, GSM, EDGE, NADC, PDC and iDEN), it offers a simple menu structure. It links to the 89601A vector signal analysis software, enabling users to control and directly extract data from the E4406A for flexible demodulation analysis on a PC.
Keysight E4406A – Features and Specifications:
Frequency range:
7 MHz to 4 GHz (RF input) and 5 Hz to 10 MHz (option B7C baseband I/Q input:
50 ohms unbalanced, 600 ohms & 1M ohms balanced)
Displayed average noise level at 1GHz:
-136 dBc/Hz
Permits measurement of baseband I and Q signals in either balanced or unbalanced systems
Dynamic range (3rd order) at 1 GHz:
102 dB
Expanded capabilities for digital demodulation and analysis with 89601A PC Software
Absolute amplitude accuracy at 1 GHz:
plus/negative 0.6 dB
Built-in test limits along with pass/fail test abilities for high-speed, reliable manufacturing
The Keysight E4406A VSA transmitter tester is available for rent from Rentaltec
