FSL6-16 6 GHz Spectrum Analyzer, Type N (f)

Spectrum Analyzer 9kHz – 6 GHzThe spectrum analyzer R&S FSL leads its class with respect to its large number of standard functions.* Full choice of detectors:
max, min, auto-peak, sample, RMS, average, quasi-peak* CP/ACP/fast ACP measurement functions with a host of predefined standards (see ACP screenshot)* Time domain power measurement* Measurement of carrier-to-noise ratio C/N or C/N0 referenced to 1 Hz or channel bandwidth* CCDF:
measurement of crest factor and amplitude probability function* Automatic test routines for:

– Occupied bandwidth (OBW)
– Third order intercept point (TOI)
– AM modulation depth * Adjustable number of trace points, max. 32001* Editable limit lines including PASS/FAIL indication* Level units:

– dBm, dBmicroV, dBmV, dBmicroA, dBpW, V, W, A * Frequency counter featuring resolution of 1 Hz with measurement time of 50 ms* Phase noise and noise marker with dBm/Hz and dBc/Hz results* n-dB down functionality for fast determination of bandwidth* Channel filters, shape factor <2* EMI filters: 200 Hz (optional), 9kHz, 120 kHz* FFT filters from 300 Hz to 30 kHz, optional 1Hz to 30 kHz* Tracking generator* Gated sweep (optional)* LAN interface, VXI11 compatible for remote control* USB interface* Help functions* Operating system: Embedded Windows XP - Easy documentation of measurements - Remote desktop functionality - Compatibility (printer drivers, network, etc.) * Power measurements with R&S NRP power sensors
