N8931A Autoranging System DC Power Supply, 80 V, 510 A, 15000

Achieve high performance, stable output power, built-in voltage and current measurements, and autoranging output voltage with the Keysight N8931A Autoranging System DC power supply.
Accelerate test system development with multiple standard I/O interfaces and save precious rack space with a compact 3U design. The Keysight (formerly Agilent) N8931A also features parallel units that can be combined to create one power supply with more than 100kW of total output power.
This DC power supply is cost effective and offers outstanding flexibility with a built-in master/slave control.
Keysight N8931A Features and Specifications:

AC input voltage: 208 VAC
DC output ratings:- Voltage: 80V- Current: 510A- Power: 15kW
Output voltage ripple and noise:- CV p-p: 320mV- CV rms: 25mV
Load effect (change from 0 to 100 percent of full load):- Voltage: 40mV- Current: 765mA
Programming accuracy (23 degrees C plus/- 5 degrees C):- Voltage: 80mV- Current: 1.1A
Measurement accuracy (23 degrees C plus/- 5 degrees C):-Voltage: 80mV- Current: 1.1A
Load transient recovery time: 1.5 ms

The Keysight (formerly Agilent) N8931A Autoranging System DC power supply (80V, 510A, 15,000W, 208 VAC) is available for rent or Rent 2 Buy at Rentaltec with 24/7 support. To know more or to get a quote, call us at +32 25323232.
