Manufacturer: Rohde & Schwarz
NRP50SN 50 GHz, Three-Path Diode Power Sensor (-70 dBm to +20 dBm)
The R&S®NRPxxS/SN power sensors use three separate diode paths, each operated in the optimum detector range. As a result, the average power can be determined with high accuracy independent of the modulation type. Measurement results are hardly affected by interfering signals or harmonics. The R&S®NRPxxS/SN power sensors therefore behave in a way similar to thermal power sensors but offer significantly higher speed. They provide up to 93 dB dynamic range with an excellent lower measurement limit of –70 dBm.• Fast and accurate power measurements for CW and modulated signals
• 100,000 readings/s
• Control and monitoring via LAN and USB
• Sensors for high-power applications
• Flexible operation with R&S®NRX base unit
