QD-980B Quantumdata 980 HDMI Protocol Analyzer

Easily accommodate up to four 980 series modules with the Teledyne LeCroy QD-980B Quantumdata 980 HDMI protocol analyzer module.
This protocol analyzer/generator module is ideal for HDMI testing of formats up to 8K formats at 1485 MHz pixel rates, deep analysis of HDMI and MHL streams, as well as HDMI and MHL compliance testing for source, sink, repeater/dongle devices.
Teledyne LeCroy QD-980B – Features and Specifications:
Configurable with up to 4 modules
Current modules:
980 HDMI 1.4 Protocol Analyzer module (p/n 95-00083)
980 HDMI 2.1 Protocol Analyzer/Video Generator module (p/n 95-00156)
980 HDMI 2.0 Video Generator module (p/n 95-00130)
980 HDMI 2.0 Protocol Analyzer/Generator module (p/n 95-00137)
980 DP 1.4 Video Generator/Analyzer module (p/n 95-00151)
980 DP 1.2 Video Generator/Analyzer module (p/n 95-00103)
980 HDMI Phy & Protocol Aux Channel Analyzer module
980 MHL CBUS Compliance Test module (p/n 95-00099)
Embedded display: 15 diagonal
Resolution:1024(H); x 768 (V); 24 bit RGB color
Power:90-264 VAC, 47-63Hz
Command line control:
Ethernet (RJ-45) for external GUI and telnet
The Teledyne LeCroy QD-980B Quantumdata 980 HDMI protocol analyzer is available for rent at Rentaltec
