Manufacturer: Keysight
E5406A Probe,34 ch: 32 single-ended data,2 single-ended or diff.
Key Feautures:
Probe Performance
< 0.7 pF equivalent load capacitance
> 2.5 Gb/s maximum data rate
Measure signals with as little as 250 mV p-p signal amplitude Connectivity
Requires up-front design of pro series soft touch connectorless footprint on PC board (no connector on the target board)
Micro spring-pin technology provides reliable contact to signal pads even when probing uneven or contaminated board surfaces
Top-side retention module eliminates need to access back of the board Compatible With:
Logic analyzers with 90-pin cable connectors Logic Analyzer Cable Connectors
All board surfaces, including lead free
Industry-standard connectorless footprint
